型號 | 通道 | 輸出電壓(V) | 輸出電流(A) | 輸出功率(kW) | 分辨率 | 設置精度 | 紋波與噪聲 | 通訊接口 | 工作電壓 | 尺寸(U) | 重量 |
---|---|---|---|---|---|---|---|---|---|---|---|
DH1798-1 | 單通道 | 80 | 60 | 1.2 | 1mV/1mA | 0.02%+30mV/0.1%+60mA | 5mVrms/40mArms | 標配LAN、USB、RS485(或 RS234),選配 GPIB | 85-265Vac,47-63Hz | 1U | 9kg |
DH1798-2 | 單通道 | 150 | 30 | 1.2 | 1mV/1mA | 0.05%+30mV/0.2%+30mA | 10mVrms/40mArms | 標配LAN、USB、RS485(或 RS235),選配 GPIB | 85-265Vac,47-63Hz | 1U | 9kg |
DH1798-3 | 單通道 | 40 | 180 | 2.4 | 1mV/3mA | 0.05%+30mV/0.2%+180mA | 10mVrms/180mArms | 標配LAN、USB、RS485(或 RS236),選配 GPIB | 85-265Vac,47-63Hz | 2U | 18kg |
DH1798-4 | 單通道 | 80 | 120 | 2.4 | 2mV/2mA | 0.05%+30mV/0.2%+120mA | 15mVrms/120mArms | 標配LAN、USB、RS485(或 RS237),選配 GPIB | 85-265Vac,47-63Hz | 2U | 18kg |
DH1798-5 | 單通道 | 160 | 60 | 2.4 | 3mV/1mA | 0.05%+30mV/0.2%+60mA | 20mVrms/60mArms | 標配LAN、USB、RS485(或 RS238),選配 GPIB | 85-265Vac,47-63Hz | 2U | 18kg |
DH1798-6 | 單通道 | 320 | 30 | 2.4 | 5mV/1mA | 0.05%+160mV/0.2%+30mA | 35mVrms/30mArms | 標配LAN、USB、RS485(或 RS239),選配 GPIB | 85-265Vac,47-63Hz | 2U | 18kg |
DH1798-7 | 單通道 | 600 | 15 | 2.4 | 10mV/1mA | 0.05%+300mV/0.2%+30mA | 60mVrms/15mArms | 標配LAN、USB、RS485(或 RS240),選配 GPIB | 85-265Vac,47-63Hz | 2U | 18kg |
DH1798-8 | 單通道 | 40 | 180 | 3 | 1mV/3mA | 0.05%+30mV/0.2%+180mA | 10mVrms/180mArms | 標配LAN、USB、RS485(或 RS241),選配 GPIB | 85-265Vac,47-63Hz | 2U | 18kg |
DH1798-1 | 單通道 | 80 | 60 | 1.2 | 1mV/1mA | 0.02%+30mV/0.1%+60mA | 5mVrms/40mArms | 標配LAN、USB、RS485(或 RS234),選配 GPIB | 85-265Vac,47-63Hz | 1U | 9kg |
DH1798-2 | 單通道 | 150 | 30 | 1.2 | 1mV/1mA | 0.05%+30mV/0.2%+30mA | 10mVrms/40mArms | 標配LAN、USB、RS485(或 RS235),選配 GPIB | 85-265Vac,47-63Hz | 1U | 9kg |
DH1798-3 | 單通道 | 40 | 180 | 2.4 | 1mV/3mA | 0.05%+30mV/0.2%+180mA | 10mVrms/180mArms | 標配LAN、USB、RS485(或 RS236),選配 GPIB | 85-265Vac,47-63Hz | 2U | 18kg |
DH1798-4 | 單通道 | 80 | 120 | 2.4 | 2mV/2mA | 0.05%+30mV/0.2%+120mA | 15mVrms/120mArms | 標配LAN、USB、RS485(或 RS237),選配 GPIB | 85-265Vac,47-63Hz | 2U | 18kg |
DH1798-5 | 單通道 | 160 | 60 | 2.4 | 3mV/1mA | 0.05%+30mV/0.2%+60mA | 20mVrms/60mArms | 標配LAN、USB、RS485(或 RS238),選配 GPIB | 85-265Vac,47-63Hz | 2U | 18kg |
DH1798-6 | 單通道 | 320 | 30 | 2.4 | 5mV/1mA | 0.05%+160mV/0.2%+30mA | 35mVrms/30mArms | 標配LAN、USB、RS485(或 RS239),選配 GPIB | 85-265Vac,47-63Hz | 2U | 18kg |
DH1798-7 | 單通道 | 600 | 15 | 2.4 | 10mV/1mA | 0.05%+300mV/0.2%+30mA | 60mVrms/15mArms | 標配LAN、USB、RS485(或 RS240),選配 GPIB | 85-265Vac,47-63Hz | 2U | 18kg |
DH1798-8 | 單通道 | 40 | 180 | 3 | 1mV/3mA | 0.05%+30mV/0.2%+180mA | 10mVrms/180mArms | 標配LAN、USB、RS485(或 RS241),選配 GPIB | 85-265Vac,47-63Hz | 2U | 18kg |
DH1798-9 | 單通道 | 80 | 120 | 3 | 2mV/2mA | 0.05%+30mV/0.2%+120mA | 15mVrms/120mArms | 標配LAN、USB、RS485(或 RS242),選配 GPIB | 85-265Vac,47-63Hz | 2U | 18kg |
DH1798-10 | 單通道 | 160 | 60 | 3 | 3mV/1mA | 0.05%+30mV/0.2%+60mA | 20mVrms/60mArms | 標配LAN、USB、RS485(或 RS243),選配 GPIB | 85-265Vac,47-63Hz | 2U | 18kg |
DH1798-11 | 單通道 | 320 | 30 | 3 | 5mV/1mA | 0.05%+160mV/0.2%+30mA | 35mVrms/30mArms | 標配LAN、USB、RS485(或 RS244),選配 GPIB | 85-265Vac,47-63Hz | 2U | 18kg |
DH1798-12 | 單通道 | 600 | 15 | 3 | 10mV/1mA | 0.05%+300mV/0.2%+30mA | 60mVrms/15mArms | 標配LAN、USB、RS485(或 RS245),選配 GPIB | 85-265Vac,47-63Hz | 2U | 18kg |
DH1798B-1 | 單通道 | 80 | 60 | 0.8 | 1mV/1mA | 0.02%+30mV/0.1%+60mA | 5mVrms/40mArms | 標配LAN、USB、RS485(或 RS232),選配 GPIB | 85-265Vac,47-63Hz | 1U | 9kg |
DH1798B-2 | 單通道 | 150 | 30 | 0.8 | 1mV/1mA | 0.05%+30mV/0.2%+30mA | 10mVrms/40mArms | 標配LAN、USB、RS485(或 RS233),選配 GPIB | 85-265Vac,47-63Hz | 1U | 9kg |
